DIY Whack a Mole Cat Toy



1) Cut the wood to the same size as the picture. The thickness is 12mm

2) Fix the woods and cat toy with the wood needle.





 3) Fix the woods with screws



4) Pass the wooden rod through the hole to connect the cat toy part with the wood box part.



4) Cover the top plate with five holes.
